Trek 2022 Emonda ALR 4

€1,599.00
Was €2,049.00
50
52
54
56
58
60
64
Buy with
Spread the cost of your purchase when buying from Revolve Bike Shop. Choose Humm at the checkout.
Don't have Humm yet? apply here

Émonda ALR 4 Disc is a lightweight aluminium road bike with powerful hydraulic disc brakes, a quality drivetrain and a frame that looks and handles like a far more expensive carbon bike. It's perfect for new riders, racers and anyone who values the better braking performance and tyre clearance provided by disc brakes.

You're a value-minded rider looking for a lightweight race bike with the added versatility and performance of disc brakes. You expect a lot of performance for your money and want a quality ride you won't immediately outgrow.

A lightweight 300 Series Alpha Aluminium frame with shaped tubes and Invisible Weld Technology for the looks and handling of a far more expensive carbon bike, a 2x10 Shimano Tiagra drivetrain, Émonda carbon fork, Bontrager Affinity tubeless-ready wheels, powerful flat-mount hydraulic disc brakes, and internal cable routing in both the frame and fork.

Émonda ALR 4 Disc is the most affordable road disc model in the line-up, but it handles like a far more expensive bike and has the looks to match. It's an extremely capable racing bike at a great price.
- Carbon looks and handling, alloy price point: Invisible Weld Technology and shaped tubes for sleek looks, light weight and incredible handling
- It climbs fast, corners on rails, and descends with confidence
- Disc brakes offer better braking performance and extra clearance for wider, more stable tyres
- Proven H2 geometry gives you a ride quality that stands up in every way to far more expensive carbon bikes
- Internal cable routing extends the life of your cables and adds to the bike's sleek look

Frame Size 56, UNI, Aluminium, Ultralight 300 Series Alpha Aluminium, Invisible Weld technology, tapered head tube, Control Freak internal routing, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle
Wheel Size Front 28
Wheel Size Rear 28
Fork Unknown
Gears DERAILLEUR, Shimano, 1 Gears
Tyres BONTRAGER,
Pedals UNKNOWN,
Wheels UNKNOWN, Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21 mm width, Presta valve Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Shifters SHIMANO, Shimano Tiagra R4720, 10-speed // Shimano Tiagra R4720, 10-speed,
Kickstand UNKNOWN, Unknown
Front Brake SH, Shimano Tiagra hydraulic disc Shimano RT70, CentreLock, 160 mm, Disc brake with hydraulic actuation
Rear Brake SH, Shimano Tiagra hydraulic disc Shimano RT70, CentreLock, 160 mm, Disc brake with hydraulic actuation
Front Derailleur SHIMANO, Shimano Tiagra 4700, braze-on
Rear Derailleur ,
Crankset SHIMANO, Shimano Tiagra 4700, 50/34, 172.5 mm length Shimano BB71, 86.5 mm, PressFit
Chain SHIMANO, Shimano Tiagra HG54, 10-speed
Headset FSA, FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Handlebar BONTRAGER, Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width
Stem BONTRAGER, Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Seatpost BONTRAGER
Saddle BONTRAGER, Bontrager Verse Comp, steel rails, 145 mm width
Front Light UNKNOWN
Rear Light UNKNOWN
Colours LITHIUM GREY, RADIOACTIVE RED TO MARIGOLD FADE
Sizes 50, 52, 54, 56, 58, 60, 64
Brand Trek
Model Year 2022
Barcodes 601842382936, 601842382950, 601842382967, 601842382974, 601842382981, 601842382998, 601842383049, 601842383056, 601842383063, 601842383070, 601842383087, 601842383094
SKUs / Part Numbers 1045460, 1045461, 1045462, 1045463, 1045464, 1045465, 1045470, 1045471, 1045472, 1045473, 1045474, 1045476

Please note: Manufacturers can sometimes change the specification of the products from time to time.
